ELV AND SECURITY
ELV, security and surveillance
CCTV, access control, fire detection and low-voltage integrations delivered as one coordinated ELV scope.
RAHCore delivery roleDesign planning · specialist coordination · project management · commissioning · lifecycle support
ENGINEERING VIEW
Low-voltage systems carry most of a building's intelligence. They are specified and cabled as one scope, not four.
CCTV, access control, detection and public address share cable routes, containment, power provision and, increasingly, a network. Tendered separately, they are installed four times over the same building.
RAHCore delivers ELV as a single coordinated scope, with one cabling design and one monitoring layer.
TECHNICAL SCOPE
What sits inside this capability
- ELV systems
- Integration
REQUIREMENT
The requirement this addresses
Separately awarded low-voltage packages produce duplicated containment, conflicting cable routes, four monitoring interfaces and no correlation between events. When an alarm is raised, the operator has to reconcile several systems manually to work out what happened.
DELIVERY
How RAHCore approaches it
We design the low-voltage network first and the subsystems onto it, so cabling, power and containment are provisioned once, and the subsystems report into a monitoring layer that can correlate across them.
DELIVERY METHOD
From planning to commissioning
- 01Risk and coverage review against the building layout
- 02Cabling, containment and device location design
- 03Specification of devices, controllers and recording infrastructure
- 04Installation, termination and device configuration
- 05Verification of coverage, access rules and alarm routing
- 06Operator training and handover
SYSTEM VISUALS
DETAILED CAPABILITY
Scope of work
Integration
- Security and surveillance integration with BMS
- Coordination with IT network infrastructure
- Data centre ELV and sensor integration
INTEGRATION
Integration with other systems
ELV overlaps with fire detection, with the IT network that increasingly carries it, and with the BMS that should see its events. Those interfaces are designed as part of the scope rather than left to subsystem vendors to resolve between themselves.
LIFECYCLE
Lifecycle and maintenance
ELV AMC covers device inspection, recording and retention checks, credential administration for access control, and corrective response. Detection systems are maintained in line with their life-safety role.
TYPICAL ENGAGEMENTS
Where this capability is applied
- CCTV and access control for a corporate or institutional site
- Data centre security, detection and monitoring
- Perimeter and entry control for a campus
- Consolidation of legacy standalone systems
- Structured cabling for low-voltage services
- Integration of ELV events into a BMS
WHY RAHCOREOne cabling design for every subsystemContainment and routes provisioned once, not four times. Events correlated, not merely collectedSubsystems report into a monitoring layer that can relate them. Life-safety scope handled as suchDetection is maintained against its role, not treated as another ELV device.
What the delivery model adds
